齒數(shù)

外圓直徑

節(jié)距圓直徑

軸孔徑D1

輪轂

PDF圖紙

DXF圖紙

De

Dp

Min

Max.

直徑Dm

長度A

inch

inch

inch

inch

inch

inch

lbs

11

LD80-3B11TQ

4.010

3.549

1

1 3/4

2 1/2

3 5/8

5.90

請咨詢

請咨詢

12

LD80-3B12TQ

4.330

3.864

1

1 7/8

2 5/6

3 5/8

7.50

13

LD80-3B13TQ

4.660

4.179

1

2 1/4

3 1/6

3 5/8

9.20

14

LD80-3B14TQ

4.980

4.494

1

2 3/8

3 4/9

3 5/8

11.00

15

LD80-3B15TQ

5.300

4.810

1

2 1/2

3 4/5

3 5/8

13.10

16

LD80-3B16TQ

5.630

5.126

1

2 3/4

4

3 7/8

15.80

17

LD80-3B17TQ

5.950

5.442

1

3

4 3/7

3 7/8

18.60

18

LD80-3B18TQ

6.270

5.759

1

3 1/4

4 3/4

3 7/8

21.20

19

LD80-3B19TQ

6.590

6.076

1

3 1/3

5

3 7/8

23.70

20

LD80-3B20TQ

6.910

6.392

1

3 1/3

5

3 7/8

26.00

21

LD80-3B21TQ

7.240

6.710

1

3 1/3

5

3 7/8

28.40

22

LD80-3B22TQ

7.560

7.027

1

3 1/3

5

3 7/8

31.00

23

LD80-3B23TQ

7.880

7.344

1

3 1/3

5

3 7/8

33.60

24

LD80-3B24TQ

8.200

7.661

1

3 1/2

5 1/4

3 7/8

37.10

25

LD80-3B25TQ

8.520

7.979

1

3 1/2

5 1/4

3 7/8

40.10

26

LD80-3B26T

8.840

8.296

1

3 1/2

5 1/4

3 7/8

42.90

30

LD80-3B30T

10.110

9.567

1 1/4

3 3/4

5 3/4

4 1/4

54.50

35

LD80-3B35T

11.710

11.156

1 1/4

3 3/4

5 3/4

4 1/4

79.50

36

LD80-3B36T

12.030

11.474

1 1/4

3 3/4

5 3/4

4 1/4

83.90

齒數(shù)

外圓直徑

節(jié)距圓直徑

軸孔徑D1

輪轂

參考重量

PDF圖紙

DXF圖紙

De

Dp

Min

Max

直徑Dm

長度A

inch

inch

inch

inch

inch

inch

Lbs

42

LD80-3C42T

13.940

13.381

1 1/4

3 4/5

6

4 1/2

84.90

請咨詢

請咨詢

45

LD80-3C45T

14.900

14.336

1 1/4

3 4/5

6

4 1/2

92.40

52

LD80-3C52T

17.130

16.562

1 1/2

3 4/5

6

4 1/2

107.00

60

LD80-3C60T

19.680

19.107

1 1/2

4 1/4

6 1/4

4 3/4

128.00

68

LD80-3C68T

22.230

21.653

1 1/2

4 1/4

6 1/4

4 3/4

140.00

76

LD80-3C76T

24.780

24.198

1 1/2

4 1/4

6 1/4

4 3/4

165.00

95

LD80-3C95T

30.830

30.245

1 1/2

4 1/2

6 3/4

5

240.00
